  • EDIT: I looked more into the ethernet + RAK boards. I was surprised to find claims that the boards that make use of the Nordic nRF microcontroller do not expose an interface for receiving commands nor do they expose a Webserver. It seems they can push data to the MQTT broker, but it might not possible to control them over the network. Here is a short discussion I found about this: https://www.reddit.com/r/meshtastic/comments/1ebcnay/rak_board_ethernet_non_web_client_access

    I can’t find evidence to support that it works today. I know that ESP32-based meshtastic devices do expose the webserver and the TCP interface. But I am not sure about how to add the ethernet interface.

    original comment

    Simplest option would probably be to make use of the RAK system. They provide modular boards for Meshtastic, and one of modules is an Ethernet interface: https://docs.rakwireless.com/product-categories/wisblock/rak13800/datasheet/

    The WisMesh Ethernet MQTT gateway is an example of an assembled module that uses the RAK19007 WisBlock Baseboard as the base that includes the power management and the slots for attaching the modules, the RAK4631 LoRa transciever module to provide the radio, and the RAK13800 Ethernet Module to provide Ethernet connectivity.

    The version that does not include an enclosure and has no Power-Over-Ethernet costs $43 through RAK. You can also get the versions with enclosure and with PoE. For PoE, you will need to have an ethernet modem/router capable of providing power over ethernet or a PoE ethernet switch.

    I don’t know much about the other Ethernet options, but there is a good chance that a good amount of them will consist of a custom 3D-printed enclosure with the RAK system inside.

    Another option is to use a Raspberry Pi or a regular computer as a bridge. The computer/raspberry pi connects to the network over ethernet and interfaces with a standard Meshtastic device via USB or via a HAT using the PI’s GPIO pins (example of the HAT: https://www.youtube.com/watch?v=91ULi9DWgds).


  • I don’t have the Heltec V3, but the model I was able to find online does support WiFi.

    You need to connect to it using some other device. It can be with Bluetooth using an app, or via USB using a web client. Once you are connected to it, you can go to Radio Configuration and add the WiFi info in the Network settings.

    Then, you need to figure out what its IP is. There are a few different ways to do it. Usually I log into my router and check the IP of the latest device to log into the WiFi.

    You can then go to that IP via your browser, and you will see this:

    You can then connect to it and interact with the device over the browser.

    To interact with it using the python library, you set the device’s IP as the NODE’s interface. Here is an example of a very simple script that will connect to the node via its IP and cause it to automatically respond with ‘Pong’ to any message that it receives that contain ‘Ping’.

    import meshtastic
    import meshtastic.tcp_interface
    from pubsub import pub
    import time

    # Your Meshtastic node's IP
    MESHTASTIC_NODE_IP = "192.168.8.149"

    def onReceive(packet, interface):
        if 'decoded' in packet and 'payload' in packet['decoded']:
            try:
                message = packet['decoded']['payload'].decode('utf-8')
                sender = packet['from']
                if "Ping" in message:
                    interface.sendText("Pong", destinationId=sender)
            except Exception as e:
                pass

    interface = meshtastic.tcp_interface.TCPInterface(hostname=MESHTASTIC_NODE_IP)
    pub.subscribe(onReceive, "meshtastic.receive")

    while True:
        time.sleep(5)  # Keep the script running





  • I would give the Letharia dye another try

    Would love to… When I was in Oregon this lichen was super abundant. At the moment I am living in Amsterdam (Netherlands), and I see mostly Xanthoria, Evernia, Rhizocarpon, and a few other lichen species that grow on city trees, but they are very small and spotty, nothing compared to the wolf lichen in Oregon. I do miss the Oregon forests with the old growth sequoia redwood trees and all that lichen.


  • 9ft of snow?! I only experienced such deep snow in an urban setting while living in Connecticut for a year. I spent a few years in Oregon but the snow in the area never got so deep while I was there. When I was in the US I was not yet able to identify many fungi as I was mainly obsessed with animals (especially salamanders) back then, so unfortunately I did not really appreciate the diversity of fungi there. Although once in Oregon I did attempt to dye some socks using a wolf lichen (Letharia vulpina) and a pressure cooker. That did not end well.



  • Cool! I just read their wiki page and it says

    A snowbank fungus, it is most common at higher elevations after snowmelt in the spring.

    Snowbank fungus is a new term for me. Not sure yet what makes a fungus thrive through snow. Maybe they have anti-freeze proteins?

    Does your area get a lot of snow?






  • Alright! Some other tips:

    • Your current microscope is a 160 mm system, so make sure that the objectives are 160 mm and not infinity.
    • Make sure the objectives have an RMS thread
    • Once you move into higher-end objectives, you will have objectives that are specialized. For example, ‘phase contrast’ objectives have a dark ring inside of them. For the olympus brand their name often ends in ‘PL’. These work with bright-field too. My 40/1.30 objective is actually a phase-contrast objective because I did not know this and ChatGPT told me it meant something different 😂 However, the objective does work well for me and I am now considering upgrading to a phase contrast-capable microscope (the BH2), so I made a good choice by accident.








  • Always happy to talk about molecules interacting with light! 😄

    This is an aspect of lichen I hadn’t really put much thought into before now.

    I have some background is in studying how light interacts with molecules, so I probably put more thought and emphasis on these things than average.

    Its been in storage for a couple of months so I may try to re-hydrate it a bit before lighting it up during the night.

    That’s cool! When keeping a collection, can you keep them alive for a long time dry?
